The 1-8x magnification range provides excellent versatility for both close-quarters shooting and more demanding medium-range engagements. At true 1x magnification, the riflescope allows rapid target acquisition and intuitive both-eyes-open shooting techniques. At higher magnification settings, the optic provides additional target detail and improved precision for longer-range shots and target identification.
The reticle is positioned in the second focal plane, meaning the reticle size remains unchanged throughout the entire magnification range. This maintains a consistent sight picture regardless of zoom level. The illuminated etched reticle features 12 brightness settings, including settings optimized for low-light use and compatibility with night vision devices.
Depending on the selected configuration, the riflescope is available with BDC or MIL reticle layouts. BDC versions are optimized for simplified holdovers, while MIL reticles provide a more advanced solution for shooters who prefer MIL-based ranging and corrections.
FEATURES
| Magnification | 1-8x |
| Tube Diameter | 30mm |
| Objective Lens Diameter | 24mm |
| Exit Pupil (mm) | 7.7mm-2.95mm (1X-8X) |
| Eye Relief (in) | 3.35-3.54″ (1X-8X) |
| FOV @ 100 Yards (ft) | 122.2-14.4′ (1X-8X) |
| Click Value | 1/2 MOA |
| Parallax Setting | 100 yds |
| Travel Per Rotation | 60 Clicks/ 30 MOA |
| Max Elevation Adjustment | 100 MOA |
| Max Windage Adjustment | 100 MOA |
| Lens Coating | Fully Multi-Coated/ Anti-fog/ Hydrophobic |
| Illumination | 12 Position Illumination turret |
| Battery | Side-mounted CR2032 Battery |
| Reticle | BDC or MOA Glass Etched Illuminated |
| Reticle position
|
2. focal plane - SFP |
| Magnification Required for Reticle Accuracy | 8x |
| Fast Focus Diopter | Yes, -2 to +2 |
| Turret Style | Push/Pull Locking Turrets with Zero Reset |
| Length | 10.67″ |
| Weight | 20.36 oz |
| Waterproof Rating | IPX7 |
| Impact Resistance | 1,100 G Forces |
