Redefining Value Optics: Premium optics for a wide range of disciplines. Dependable, accurate, affordable.
All models in the Vantage HD 30 range feature Hawke’s H2 optics, fully multi-coated with 11 layers for exceptional light transmission, which boast a stunning wide-angle field of view and a 3.5 inch eye relief. Featuring red and green illumination with a stepped rheostat, the Vantage HD 30 delivers a crisp, daylight-visible central aim point. Side Focus adjustment allows for parallax and focus correction from 10 yards to infinity.
The supplied XL removable zoom magnification throw lever allows you to make rapid and effortless zoom magnification adjustments, ideal when speed is essential, or when wearing gloves.
.223/.308 Marksman Reticle (16x): Registered reticle design exclusive to Hawke. Bullet Drop Compensating (BDC) aim points calculated for your specific caliber. Easy to zero and outstanding downrange accuracy with illuminated aim points for all lighting conditions. Distances etched into the reticle field of view, designed for use on maximum magnification.
Designed to accommodate a variety of ammunition for both .223/5.56 and .308. Zero on 16x magnification at 100 yards and the bullet drop compensating reticle provides accurate aim points in 100 yard increments out to 700 yards.
The scope can also be used for 100m zero with aimpoints correct in metric when the magnification is set to 13.7x.
Features
30mm Monotube Chassis
Exposed, Locking Elevation & Windage
Illuminated Glass Reticle
11 Layer Fully Multi-Coated Lenses
3.5 Inch Eye Relief
Nitrogen purged
Shockproof
Waterproof
Fog proof
All calibre rated
Hawke Warranty
Specifications
Objective Lens: 50mm
Reticle: .223/.308 Marksman (16x)
Illumination: 5 Levels (Red & Green)
Illumination Control: Stepped Rheostat
Parallax: Side Focus
Magnification: 4 - 16x
Optical System: System H2
Focal Plane: SFP (Second Focal Plane)
Scope Tube: 30mm
Field of View: 28.8 - 7.8ft @100yds | 9.6 - 2.6m @100m
Field of View (°): 5.5 - 1.5
Eye Relief: 3.5in | 90mm
PX/Focus (Error free from): 10yds - ∞ | 9m - ∞
Exit Pupil: 0.49 - 0.12″ | 12.5 - 3.1mm
Click Value: 1⁄ 4MOA
Elevation Turret Clicks (max): 95 MOA
Windage Turret Clicks (max): 95 MOA
Ocular Type: Fast Focus
Power Selector: Knurled Posi-Grip with Removable Zoom Lever
Lens Coating: Fully Multi-Coated - 11 Layers
Length: 13.7in | 347mm
Weight: 26.1oz | 740g
Turret Type (Elevation): Exposed, Locking, Resettable
Turret Type (Windage): Exposed, Locking, Resettable
