Designed for all hunting disciplines - from varmint to big game. All models feature Hawke's H5 optics which boasts a stunning 24° ultra-wide field of view with generous 100mm eye relief. The H5 illumination system features multi-LED technology for high intensity illumination.
LR Dot Reticle: The LR Dot reticle was developed around a typical centrefire trajectory, like the .308 Winchester round, which is popular around the world for shooting fairly large game. It also suits some of the faster bullets that might be used for hunting foxes and similar quarry. This design also makes it suitable for European shooters who might prefer a metric set of figures and therefore to zero their rifle in for 100 metres on the centre crosshair and use the lower aim points for 200, 300, 400 and 500 metres. A useful tip: at 16x magnification, the thick posts to the right and left of the centre dot would bracket the body length of a Roe deer at 100yds; a popular sized animal to hunt with this type of reticle.
Features
Exposed, Locking Turrets
30mm Mono-tube chassis
Side Focus
Illumination
Ultra-wide Angle 24° FOV
High volume eyebox
100mm eye relief
Multi-LED high intensity reticle
High grade, low dispersion Crown glass
18 layer Fully Multi-Coated lenses
High torque rubber zoom ring
Fast focus eyebell
Nitrogen purged
Shockproof
\Waterproof
Fog proof
All calibre rated
Specifications
Objective Lens: 50mm
Reticle: LR Dot (16x)
Illumination: 6 Levels (Red)
Illumination Control: Stepped Rheostat with Off Positions In-between
Parallax: Side Focus
Magnification: 6 - 24x | 4 - 16x
Optical System: System H5
Focal Plane: SFP (Second Focal Plane)
Scope Tube: 30mm
Field of View: 20.7 - 5.1ft @100yds | 6.9 - 1.7m @100m
Field of View (°): 4 - 1 | 6 - 1.5
Eye Relief: 4in | 102mm
PX/Focus: 15yds - ∞ | 14m - ∞
Exit Pupil: 0.33 - 0.08″ | 8.3 - 2.1mm
Click Value: 1⁄ 4MOA
Elevation Turret Clicks (max): 75 MOA
Windage Turret Clicks (max): 75 MOA
Ocular Type: Fast Focus
Power Selector: Rubber Coated Posi-Grip
Lens Coating: Fully Multi-Coated - 18 Layers
Length: 14.5in | 369mm
Weight: 22.7oz | 644g
Turret Type (Elevation): Exposed. Locking. Resettable
Turret Type (Windage): Exposed. Locking. Resettable
