Designed for all hunting disciplines - from varmint to big game. All models feature Hawke's H5 optics which boasts a stunning 24° ultra-wide field of view with generous 100mm eye relief. The H5 illumination system features multi-LED technology for high intensity illumination.
LR Dot Reticle: The LR Dot reticle was developed around a typical centrefire trajectory, like the .308 Winchester round, which is popular around the world for shooting fairly large game. It also suits some of the faster bullets that might be used for hunting foxes and similar quarry. Many hunters like to use the same magnification for the rifle scope as their binoculars so the LR Dot reticle markings were designed at 8x magnification. This design also makes it suitable for European shooters who might prefer a metric set of figures and therefore to zero their rifle in for 100 metres on the centre crosshair and use the lower aim points for 200, 300, 400 and 500 metres. A useful tip: at 8x magnification, the thick posts to the right and left of the centre dot would bracket the body length of a Roe deer at 100yds; a popular sized animal to hunt with this type of reticle.
Features
Capped Low-Profile Turrets
30mm Mono-tube chassis
Illumination
Ultra-wide Angle 24° FOV
High volume eyebox
100mm eye relief
Multi-LED high intensity reticle
High grade, low dispersion Crown glass
18 layer Fully Multi-Coated lenses
High torque rubber zoom ring
Fast focus eyebell
Nitrogen purged
Shockproof
Waterproof
Fog proof
All calibre rated
Specifications
Objective Lens: 56mm
Reticle: LR Dot (8x)
Illumination: 6 Levels (Red)
Illumination Control: Stepped Rheostat with Off Positions In-between
Parallax: Fixed
Magnification: 3 - 12x
Optical System: System H5
Focal Plane: SFP (Second Focal Plane)
Scope Tube: 30mm
Field of View: 41.5 - 10.4ft @100yds | 13.8 - 3.5m @100m
Field of View (°): 7.9 - 2
Eye Relief: 4in | 102mm
PX/Focus: 100yds | 91m
Exit Pupil: 0.74 - 0.19″ | 18.7 - 4.7mm
Click Value: 1⁄ 4MOA
Elevation Turret Clicks (max): 110 MOA
Windage Turret Clicks (max): 110 MOA
Ocular Type: Fast Focus
Power Selector: Rubber Coated Posi-Grip
Lens Coating: Fully Multi-Coated - 18 Layers
Length: 13.7in | 347mm
Weight: 22.4oz | 635g
Turret Type (Elevation): Capped. Low-Profile. Resettable
Turret Type (Windage): Capped. Low-Profile. Resettable
