Designed for all hunting disciplines - from varmint to big game. All models feature Hawke's H5 optics which boasts a stunning 24° ultra-wide field of view with generous 100mm eye relief. The H5 illumination system features multi-LED technology for high intensity illumination.
Tactical Dot (4x) Reticle: Glass etched with illuminated quick acquisition circle and central aim point. Additional aim points down to 10 mil spacing when on 4x magnification.
L4A Dot Reticle (2 MOA): A variant of the classic L4 reticle, the L4A Dot uses a more open outer post design to keep more of the target visible while aiming. 30″ spacing from center to post at 100yds when on 4x magnification. This is equivalent to 83cm at 100m.
Features
Exposed, Locking Turrets
30mm Mono-tube chassis
Illumination
Ultra-wide Angle 24° FOV
High volume eyebox
100mm eye relief
Multi-LED high intensity reticle
High grade, low dispersion Crown glass
18 layer Fully Multi-Coated lenses
High torque rubber zoom ring
Fast focus eyebell
Nitrogen purged
Shockproof
Waterproof
Fog proof
All calibre rated
Specifications
Objective Lens: 24mm
Reticle: Tactical Dot (4x) | L4A Dot (2 MOA)
Illumination: 6 Levels (Red)
Illumination Control: Stepped Rheostat with Off Positions In-between
Parallax: Fixed
Magnification: 1 - 4x
Optical System: System H5
Focal Plane: SFP (Second Focal Plane)
Scope Tube: 30mm
Field of View: 124.5 - 31.1ft @100yds | 41.5 - 10.4m @100m
Field of View (°): 23.4 - 5.9
Eye Relief: 4in | 102mm
PX/Focus: 100yds | 91m
Exit Pupil: 0.94 - 0.24″ | 24 - 6mm
Click Value: 1⁄ 10MRAD
Elevation Turret Clicks (max): 81 MRAD
Windage Turret Clicks (max): 81 MRAD
Ocular Type: Fast Focus
Power Selector: Rubber Coated Posi-Grip
Lens Coating: Fully Multi-Coated - 18 Layers
Length: 11.1in | 282mm
Weight: 18.3oz | 518g
Turret Type (Elevation): Exposed. Locking. Resettable
Turret Type (Windage): Exposed. Locking. Resettable
