Guide TU Series Thermal Imaging Riflescope TU450

DESCRIPTION

HD OLED display, with 1x~4x smooth zoom, provides a comfortable visual experience

10 sets of zero calibration configurations can be saved, no need to recalibrate for different instruments

The reticle density can be zoomed in synchronously with the image to ensure the aiming accuracy 10 kinds of reticles, 6 kinds of reticle colors, 10 grades of reticle brightness, for your selection Support photo and video, record wonderful moments at any time, easy to share

Remote control by WIFI or Bluetooth, for diversified usage

Rugged and durable, IP67 rating, working temperature -30°C~50°C, no fear of severe weather

10hrs super long duration time, changing battery without turn off, ensuring full day operations

AluX Accu ringe in 30mm INCLUDED

SPECIFICATIONS

• Infrared detector:
  • Detector type: VOx
  • Detector resolution and pitch: 400 × 300, 17 μm

  • Spectral range: 8 to 14 μm
  • NETD: ≤30mk @ F1 25°C

• Lens:
  • Focal length: 50 mm; F1.2
  • Focus: Manual

  • Field of angle: 7.78° × 5.84°

• Frame rate:
  • Output frame frequency: 50 Hz
• Zoom:

  • Optical zoom: 3.2x
  • Digital zoom: 1 – 4x

• Power:
  • Battery type: Single 18650 battery (built-in) and customized battery (external)
  • Battery life: ≥ 5 hours

• Interface:

  • USB: Type C, supporting power delivery, charging, and reading data from memory card
  • Video interface: micro HDMI

  • External expansion: External Display and Bluetooth remote control

  • Mechanical interface: Picatinny

• Display:

  • Display type: 0.39’’ OLED
  • Resolution: 1024 × 768

  • Eyepiece: Exit pupil distance ≥ 48 mm Exit pupil diameter ≥ 8 mm Diopter ± 4

  • Eyepiece zoom: 14x

  • Video output: Digital video

• Button:
  • Button functions: Power / Menu / Zoom / Photo / Video
• Environmental:
  • Operating temperature range: -30 °C to 50 °C
  • Storage temperature range: -45°C to 70°C

  • Humidity: 10 % to 95 % non-condensing

  • Shock: 500 G at 1 ms half sine pulse (as per IEC60068-2-27)

  • Vibration: 10 Hz - 150 Hz - 10 Hz 0.15 mm (as per IEC60068-2-6)

  • Encapsulation: IP67
• Physical:
  • Weight: ≤950 g
  • Size (L × W × H): 377 × 107 × 69 mm

  • Standard: Type C cable, lens cap, 5V2A adapter (China, US, Britain, Australia and Europe), customized battery, customized battery charger (desktop charger), Micro HDMI cable, eye mask, two Picatinny rail clips, quick start guide

  • Optional: Bluetooth remote control, customized battery.


FUNCTIONS

• Smooth zoom: Available
• Screen brightness adjustment: 10 levels

• Detector brightness adjustment:10 levels

• Detector contrast adjustment:10 levels

• Image enhancement: Available

• Scene modes: Enhanced, Highlight and Natural

• Ultra power saving mode + Video recording + Image capturing + Hot spot tracking + Time setting: Available

• WIFI: Transmission of real-time video via WIFI for remote control in the 2.4G frequency band and within 15 meters

• Color palettes: White Hot, Black Hot, adjustable Red Hot , Green Hot, Iron Red, Blue Hot

• Compensation modes: Shutter and scene compensation

• Zero calibration: 50 m / 100 m / 200 m / 300 m / 500 m

• Line type: 10 types

• Line brightness: 10 types

• Line color: Black / white / yellow / green / red / blue

• Rough ranging: Available

• Automatic shutdown: Closed, 15, 30 or 60 mins

• Auto sleep: Closed, 5, 10, or 15 mins

• Language settings: Chinese / English / Russian / German / French

• Watermark settings: Closed, setting of date or date and time

• PIP: Upper left, Upper middle, Upper right, Closed, PIP with division line

• Restore to default: Available

• Start up: 18 s

• Memory capacity: 16GB
